No-Drill Adapter Kit: Installing Your Bed Rack Without a Factory-Installed Bed Rail
Disclaimer:
Before we dive in, here are a few important reminders:
• If you’re unsure about any part of the installation or don’t feel comfortable, consider getting help from a qualified individual or a local licensed shop.
• This installation may require hand tools or power tools, and some parts can be heavy or awkward. Always use the appropriate protective gear and ask a friend to help.
• We are not liable for any issues that arise during or after installation. Follow all instructions carefully, use common sense, and regularly check the hardware for wear and tightness.
• Use thread locker (like Loctite) on any bolts that may loosen over time.
• Your safety, and the safety of others, is paramount. Take a moment to assess risks and ensure these products are the right fit for your needs.
Now, let’s get started!
Introduction
This sub-guide is for vehicles that do not have factory-installed bed rails. Many newer models, like Toyotas, Nissans, and Jeep Gladiators, come with bed rails (shown below), but if your vehicle lacks them, follow these instructions for installation using the No-Drill Adapter Kit.
Newer Toyotas, Nissans and Jeep Gladiators usually have factory bed rails. (shown below)
Step 1: Identify the Adapter Kit
If your vehicle doesn’t have factory bed rails, you’ll need to use the No-Drill Adapter Kit.
Step 2: Position the Adapter Plates
Place the adapter plate on the back side of the Z bracket, behind the lip that extends down along the edge of your truck bed.
Step 3: Tighten and Align the Plates
Tighten the bolts to clamp the two plates together. Make sure to align the ears on the adapter plates so they sit as high as possible behind the lip of your truck box.
Step 4: Secure with Aluminum Pinch Clamps
Use the 8 aluminum pinch clamps you purchased separately (available at most local truck outfitter supply stores, or Amazon).
• Note: If you have a tonneau cover that already uses these aluminum clamps, you may be able to reposition the clamps to pinch the ears of the adapter plates.
Step 5: Continue the Installation
Once you’ve secured the adapter plates and clamps, refer back to the main bed rack installation instructions to complete the process:
